Hikmicro Habrok Pro HQ50L4K 50mm LRF Thermal night vision binocular

HIKMICRO HABROK Pro HQ50L4K Multi-Spectrum Binocular

The HIKMICRO HABROK Pro HQ50L4K is a high-performance multi-spectrum binocular combining thermal imaging, 4K digital imaging, laser rangefinding and infrared illumination in one versatile unit.

Featuring a highly sensitive 640 × 512 thermal detector with <15mK NETD and a 50mm thermal lens, it delivers excellent detail and target recognition across challenging weather and lighting conditions.

The advanced 4K digital detector with 60mm lens provides exceptional daytime and low-light image quality, while the integrated 1000m laser rangefinder and replaceable 850nm IR illuminator add even greater versatility.

Designed for hunting, wildlife observation, searching, rescue applications and marine use, the HABROK Pro combines multiple observation technologies into one compact binocular.

Key Features

• 640 × 512 resolution, 12μm thermal detector

• High-sensitivity thermal module with NETD <15mK

• 50mm F1.0 thermal lens

• Thermal detection range up to 2600m

• 3840 × 2160 4K CMOS digital detector

• 1920 × 1080 0.49" OLED display

• Built-in 850nm IR illuminator

• Integrated 1000m laser rangefinder

• 10.5+ hours continuous operating time

• Replaceable rechargeable battery pack

• Compact ergonomic design

• Weight: 975g

Laser Rangefinder

• Laser Safety Class: Class 1

• Wavelength: 905nm

• Maximum Measuring Range: 1000m

• Minimum Measuring Range: 10m

• Measurement Accuracy: ±1m

Thermal Module

• Image Sensor: VOx Uncooled Focal Plane Arrays

• Resolution: 640 × 512

• Frame Rate: 50Hz

• Pixel Interval: 12μm

• Response Waveband: 8μm–14μm

• NETD: <15mK (@25°C, F#=1.0)

• Lens: 50mm, F1.0

• Focus Mode: Focus Ring

• Detection Range: 2600m

• Minimum Focusing Distance: 5m

• Magnification: 4.3×–20.0× (4.6×)

• Field of View: 8.8° × 5.3° / 15.4m × 9.3m @ 100m

Optical Module

• Image Sensor: 1/1.8" Progressive Scan CMOS

• Resolution: 3840 × 2160

• Lens: 60mm, F2.2

• Minimum Working Distance: 3m

• Focus Mode: Focus Ring

• Magnification: 5.5×–22.0× (4×)

• Field of View: 7.3° × 4.1° / 12.6m × 7.2m @ 100m

• Smart IR: Yes

• IR Wavelength: 850nm

• Night Viewing Range: 400m

• Replaceable IR Illuminator: Yes

Image & Display

• Display: 0.49" OLED, 1920 × 1080

• Thermal Palettes: Black Hot, White Hot, Red Hot, Fusion

• Optical Modes: Day, Night, Auto

• FFC Modes: Auto, Manual, External Correction

• Exit Pupil: 8mm

• Eye Relief: 15mm

• Diopter Range: -5D to +3D

• Brightness Adjustment: Yes

• Tone Adjustment: Cold / Warm

• Contrast Adjustment: Yes

• Zoom Pro: Yes

• Image Pro 2.0: Yes

System Features

• Video Recording

• Snapshot Capture

• Audio Recording

• Standby Mode

• 64GB Built-in EMMC Storage

• Picture-in-Picture (PIP)

• Wi-Fi Hotspot

• Hot Track

• Digital Magnetic Compass

• GPS

• Local Album

Power Supply

• Battery: Replaceable & rechargeable Li-ion battery pack

• Operating Time: Up to 10.5 hours*

• USB Type-C: 5V/9V DC, 3A

• Supports external power supply

• Supports direct charging

*Operating time measured at 25°C with hotspot off and LRF and Zoom Pro on.

General

• Protection Rating: IP67

• Dimensions: 142.9 × 79.7 × 230.5mm

• Weight: 975g with battery pack

• Operating Temperature: -30°C to +55°C

• Interpupillary Adjustment: 60–74mm

• Mounting Adapter: 1/4"-20 UNC
