This updated favourite hands an unfair advantage to shooters who seek to keep the upper hand in every situation, from close quarters to long range shots.
The illumination dial is cleanly integrated into the side focus adjustment knob for easy access and streamlined performance.
The reticle offers shooters highly functional, intuitive, and detailed hold points, yet remains uncluttered for optimal viewing and features
There are 10 intensity levels with off positions between each, for a fast return to your previous setting.
EBR-4 RETICLE (MOA)
Hash-marked ranging reticle using MOA or MRAD based subtension lines for ranging, holdover, and windage corrections.
XD™ Lens Elements - Extra low dispersion (XD) glass increases resolution and colour fidelity, resulting in crisp, sharp images.
XR™ Fully Multi-Coated - Proprietary coatings increase light transmission with multiple anti-reflective coatings on all air-to-glass surfaces.
Second Focal Plane Reticle Scale of reticle maintains the same ideally-sized appearance. Listed reticle subtensions used for estimating range, holdover and wind drift correction are accurate at the highest magnification.
Glass Etched Reticle - Protected between two layers of glass for optimum durability and reliability.
Illuminated Reticle - Provides precise aiming under low light conditions.
30 mm Tube - Provides greater strength and wider adjustment latitude when compared to a 1 inch tube.
One Piece Tube - Maximizes alignment for improved accuracy and optimum visual performance, as well as ensures strength and water resistance.
Aircraft Grade Aluminium - Constructed from a solid block of aircraft grade aluminium for strength and rigidity.
Waterproof - O-ring seals prevent moisture, dust and debris from penetrating the riflescope for reliable performance in all environments.
Fogproof - Argon gas purging prevents internal fogging over a wide range of temperatures.
Shockproof - Rugged construction withstands recoil and impact.
Hard Anodized Finish - Highly durable low glare matte finish helps camouflage the shooter's position.
ArmorTek - Ultra hard, scratch resistant coating protects exterior lenses from scratches, oil and dirt.
Tactical Style Turrets - Exposed turrets provide fast, accurate and easily read elevation and windage adjustments.
INTERNAL MECHANISM DESIGN
RZR Zero Stop - Zero Stop mechanism prevents the turret from dialing below sight in range.
Precision Force Spring System - Uses premium components in the erector spring system to ensure maximum repeatability and ease of adjustment.
Precision Glide Erector System - Uses premium components in the zoom lens mechanism to ensure smooth magnification changes under the harshest conditions.
Radius Bar - Fibre optic turret rotation indicator provides a highly visible and tactile point of reference for turret rotations. US Patent 7,937,879
Fast Focus Eyepiece - Allows quick and easy reticle focusing.
Built In Accuracy Features
Matching MOA turrets and reticles facilitate fast and accurate shooting at extended ranges.
Magnification - 5-25X
Objective Lens Diameter - 50 mm
Eye Relief - 3.4 in
Field of View - 24.1-4.8 feet/100 yards
Tube Size - 30 mm
Turret Style - Tactical RZR Zero Stop
Adjustment Graduation 1/4 MOA
Travel per Rotation 25 MOA
Max Elevation Adjustment 70 MOA
Max Windage Adjustment 35 MOA
Parallax Setting - 25 yards to Infinity
Length - 40.6cm / 16 inches
Weight - 884 grams / 31.2 ounces
